技术参数SPECIFICATIONS
适用线规(Applicablewires):AWG24#~12#
温度范围(Temperaturerange):-20℃~85℃
额定电压(Voitagerating):300V.Ac/Dc
额定电流(Currentrating):18Amax
接触电阻(Contactresistance):≤0.01Ω
绝缘电阻(Insulationresistance):≥1000MΩ
耐压(Withstandvoltage):1500V.Ac/1min
材料(Material):
壳体(Housing):尼龙(PA66)UL94V-2(0)
端子(Terminal):磷青铜(PhosbronzeTin/plated)
黄铜(BrassTin/plated)
